DIN Rail Mount 10 Position Power Distribution Fuse Module Board, For AC/DC 5~32V.

00
:
00
:
00

$ 34

4.8 (77)

In stock
Arrives by Tomorrow
.
Order within 00 hr 00 min
Order today and save $8.84 ! The discount is automatically applied on the checkout page!
Hot sale!

114 people are currently viewing this product.

Only 63 items left, while supplies last!

DIN Rail Mount 10 Position Power Distribution Fuse Module, for 5 to 32V Work voltage: AC or DC 5~32V, total current rating 40Amp. P2-1 to P2-10 output terminals: pitch - 7.5mm/0.295, maximum current 10A for per position, wire size 26~12 AWG, stripping length 7mm, Metric M2.5 slotted screw. Fuse holders for Medium Blade ATO/ATC Fuse, factory-installed fuses 5Amp. with fuse fail indication function. Fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm / 32mm / 15mm rail, and the carrier can be taken apart for panel mount use. Work voltage: AC or DC 5~32V, total current rating 40Amp. PCB Dimensions: 150mm x 72.5mm x 29mm (W x L x H).
